8-80 Section 8-6 - Mechanical Parts- Replacement Procedures
D
IRECTION 5771498-100, REVISION 6 VENUE™ SERVICE MANUAL
PRELIMINARY
8-6-2 MPB Guide L and Guide R Replacement Procedure
NOTE: The procedure below is the same whether replacing MPB Guide L or MPB Guide R that are mirrored items
attached to the Receptacle Box side walls.
8-6-2-1 Tools
Appropriate Phillips screwdriver.
8-6-2-2 Time Required
15 min
8-6-2-3 Preparations
1.) Shut down the Venue™ ultrasound unit, as described in Power Shut Down .
2.) Make sure the On/Off power switch is set to Off.
3.) Make sure the system is standing securely on a level surface, with the wheels in the locked position.
8-6-2-4 MPB Guide L/R Removal Procedure
1.) Remove all accessories.
2.) Remove the following covers: RS Probe cover, Lower Front eTower, Side Covers, MPB Power Door
3.) Remove the MPB Module.
4.) Unscrew the two mounting screws that hold the Guide L/R.
Refer to Table 9-5 on page 9-4.
• Accessories - Replacement Procedures
• RS Probe Cover Removal Procedure
• Lower Front eTower Cover Removal Procedure
• Left Side eTower Cover Removal Procedure
• Right Side eTower Cover Removal Procedure
• MPB Door Cover Removal Procedure
• MPB Module Removal Procedure
