Chapter 8 - Replacement Procedures 8-81
D
IRECTION 5771498-100, REVISION 6 VENUE™ SERVICE MANUAL
PRELIMINARY
5.) Remove the Guide.
8-6-2-5 MPB Guide L/R Installation Procedure
1.) Attach the MP Guide L/R.
2.) Tighten the two mounting screws to secure the guide to the receptical box.
3.) Install the MPB Module.
Figure 8-64 MPB Guide L/R- Mounting Screws
Figure 8-65 MPB Guide L/R- Mounting Screws
• MPB Module Installation Procedure
MPB Guide L/R
Mounting Screws
To Next Page
