8-6-7 Plastic Cable Guide for CFE Replacement Procedure
8-6-7-1 Tools
Appropriate Phillips screwdriver
8-6-7-2 Time Required
15 min
8-6-7-3 Preparations
1.) Shut down the Venue™ ultrasound unit, as described in Power Shut Down .
2.) Make sure the On/Off power switch is set to Off.
3.) Make sure the system is standing securely on a level surface, with the wheels in the locked position.
8-6-7-4 Plastic Cable Guide for CFE Removal Procedure
1) Remove all accessories.
2) Remove the following covers: RS Probe cover, Lower Front eTower, Left side eTower, Right Side
eTower, Riser Thermal Cover
3.) Open the two fastening latches on the left side of the FE door assembly, loosen the captive screw
and carefully open the door. See Figure 8-19.
4.) Secure the door by clipping the door with door support- Figure 8-19.
5.) Remove the BIB cable from the Plastic Cable Guide for CFE as follows:
• Release the two screws.
Refer to Table 9-5 on page 9-4.
• Accessories - Replacement Procedures
• RS Probe Cover Removal Procedure
• Lower Front eTower Cover Removal Procedure
• Left Side eTower Cover Removal Procedure
• Right Side eTower Cover Removal Procedure
• Riser Thermal Cover Removal Procedure
