8-64 Section 8-4 - System Modules- Replacement Procedures
D
IRECTION 5771498-100, REVISION 6 VENUE™ SERVICE MANUAL
PRELIMINARY
8-4-12 T-PSB Module Replacement Procedure
8-4-12-1 Tools
Appropriate Phillips screwdriver.
8-4-12-2 Time Required
15 minutes
8-4-12-3 Preparation
1.) Shut down the Venue™ ultrasound unit, as described in Power Shut Down .
2.) Make sure the On/Off power switch is set to Off.
3.) Make sure the system is standing securely on a level surface, with the wheels in the locked position.
8-4-12-4 T-PSB Module Removal Procedure
1) Remove all accessories.
2) Remove the following covers: RS Probe Cover, Lower Front eTower, Left side eTower, and Right
Side eTower.
3.) Remove the T-FEPS module.
4.) Open and remove the full Front End assembly and place it on your laps in order not to damage the
probe locker levers.:
5.) Remove the T-CFE module.
The T-PSB module is now separated from other parts.
When performing these procedures, take precautions to avoid damage of
electrostatic-sensitive components. Always have the ESD wrist strap
connected either to the DIB chassis or to the GND plug at the rear of the
scanner, and to your hand.
FRU Part #
Refer to Table 9-10 on page 9-10.
Accessories - Replacement Procedures
RS Probe Cover Removal Procedure
Lower Front eTower Cover Removal Procedure
Left Side eTower Cover Removal Procedure
Right Side eTower Cover Removal Procedure
Front End Power Supply Removal Procedure
Full Front End Removal
T-CFE Module Removal Procedure
