8-218 Section 8-10 - Functional Checks to be Performed after Replacement Procedures
D
IRECTION 5771498-100, REVISION 6 VENUE™ SERVICE MANUAL
PRELIMINARY
Halo Handle Replacement Procedure
• Perform 7-3-3 -System Diagnostics
• Select
Full System Diagnostics without JIG.
• Mechanical Functions Checks
• Ground Continuity Test
Articulated Arm Replacement Procedure
• Perform 7-3-3 -System Diagnostics
• Select
Full System Diagnostics without JIG.
• Mechanical Functions Checks
• Ground Continuity Test
Riser Replacement Procedure
• Perform 7-3-3 -System Diagnostics
• Select
Full System Diagnostics without JIG.
• Mechanical Functions Checks
• Ground Continuity Test
Casters Replacement Procedure
• Mechanical Functions Checks
Plastic Cable Guide for CFE Replacement
Procedure
• Perform 7-3-3 -System Diagnostics
• Select
Full System Diagnostics without JIG.
MPB Blower (Fan) Replacement Procedure
• Perform 7-3-3 -System Diagnostics
• Select
Full System Diagnostics without JIG.
IPP Module Replacement Procedure
• Perform 7-3-3 -System Diagnostics
• Select
Full System Diagnostics without JIG.
• Ground Continuity Test
Cables
MPB Rear USB Cable Replacement
Procedure
• Perform 7-3-3 -System Diagnostics
• Select
Full System Diagnostics without JIG.
ON/OFF Switch Cable Replacement
Procedure
• Perform 7-3-3 -System Diagnostics
• Select
Full System Diagnostics without JIG.
PCIe Cable Replacement Procedure
• Perform 7-3-3 -System Diagnostics
• Select
Full System Diagnostics without JIG.
MPB to BIB Control Cable Replacement
Procedure
• Perform 7-3-3 -System Diagnostics
• Select
Full System Diagnostics without JIG.
Printer USB Cable Replacement Procedure
• No functional checks are required
Table 8-4 Replacement Procedures - Functional Checks Required (Continued)
Repl. Part Category Replacement Procedure Functional Checks Required
