3.2 Machine equipment
3.2.1 GEDA MINI 60 S
8 = Pivot arm
10 = Non-twisting device with load
hook
11 = Vertical frame (scaffolding)
1 = Winch MINI 60 S
2 = Rope drum with drum flexible
drum guard
3 = Cable
4 = Tilting mechanism (limit stop)
5 = Plug for control
6 = Mains supply line
7 = Safety bar closure
4
5
6
1
8
10
2
11
3
7
