GEDA MINI 60 S - Fall protection “ECO S”; “Simple”

Technical description GEDA
®
MINI 60 S / MAXI 120 S / MAXI 150 S
Assembly and Operating Manual 28 / 90 BL068 GB Edition 03/2015
3.3.6 Fall protection “ECO S” / “Simple”
Protect against persons falling from heights of more than 2 m [6.5 ft].
(Refer to national provisions)
Landing-level safety gate “ECO S”
Item No. 42500
Width: 0.85 m [2.8 ft]
Weight: 22 kg [48 lb]
1 = Landing level safety gate
2 = Railing rope hoists
“Simple” loading point protection rails
Item No. 01206
Width: 1.4 m [4.5 ft]
Weight: 29 kg [64 lb]
5 = Safety gate
1
2
2
5
