GEDA MINI 60 S - Geda Maxi 120 S; 150 S

Technical description GEDA
®
MINI 60 S / MAXI 120 S / MAXI 150 S
Assembly and Operating Manual 22 / 90 BL068 GB Edition 03/2015
3.2.2 GEDA MAXI 120 S / 150 S
8 = Pivot arm
9 = Pivot arm mounting MAXI 120 S
10 = Non-twisting device with load
hook
11 = Vertical frame (scaffolding)
1 = Winch MAXI 120 S / 150 S
2 = Rope drum with drum flexible
drum guard
3 = Cable
4 = Tilting mechanism (limit stop)
5 = Plug for control
6 = Mains supply line
4
5
6
1
8
10
2
11
3
9
