GEDA
®
MINI 60 S / MAXI 120 S / MAXI 150 S Assembly
BL068 GB Edition 03/2015 47 / 90 Assembly and Operating Manual
5.2 Assembly procedure
The installation plan shows the basic assembly stages and their chrono-
logical sequence. However, assembly is in principle based on the de-
tailed instructions in this manual. Depending on the working equipment
available / number of installation engineers, tasks may be carried out in
parallel or the sequence of the installation steps may be changed. If the
sequence is changed, the amended installation plan must be checked
by the operating company to ensure that it is sensible and that there are
no potential hazards and must be subsequently approved.
Assembly schematic GEDA MINI 60 S / MAXI 120 S / 150 S
Assembling scaffolding lift
Assemble the winch on the scaffolding support
Align the winch
Assemble the pivot arm vertically above the winch
Connect the manual control
Insert mains plug at the building site main cabinet
Assembling scaffolding lift
Assembling the wire rope
Cordon off / indicate the hazard area
Secure the loading positions using fall protection
Install protection made from parts of the scaffolding or
install landing-level safety gate
Inspection after assembly
Before commissioning each time, check the machine
Instruct authorized personnel to use.
