MINI 60 S / MAXI 120 S / MAXI 150 S Transport
BL068 GB Edition 03/2015 45 / 90 Assembly and Operating Manual
4.2.2 Transportation using lifting equipment
WARNING
Danger to life
Raised load!
Do not stand under suspended loads.
Do not stand on a suspended load.
Only lift loads at the suspension points.
Only use suitable lifting gear.
If lifting equipment is available, there is the op-
tion to suspend the device from a load hook.
 Suspend the load hook (3) in the holes pro-
vided for the safety bar closure.
4.2.1 Transportation using a transportation frame
The transportation frame (4) is used
for easier transportation of the
winch in the stores and on the con-
struction site.
The machine is attached by bolts to
the transportation frame (4) on the
scaffolding and can remain there.
3
4
