GEDA MINI 60 S - Equipment as Accessories; Adapter; Pivot Arm Mounting for MINI 60 S

Technical description GEDA
®
MINI 60 S / MAXI 120 S / MAXI 150 S
Assembly and Operating Manual 24 / 90 BL068 GB Edition 03/2015
3.3 Equipment as accessories
3.3.1 Adapter
For adapting the pivot arm to a vertical frame (scaffolding) without pro-
truding crossbar studs.
Item No. 01409
Weight: 0.6 kg [1.3 lb]
1 = Adapter
2 = Vertical frame
(scaffolding)
3 = Pivot arm
3.3.2 Pivot arm mounting for MINI 60 S
The pivot arm mounting serves for fastening the pivot arm between
scaffolding levels.
Item No. 01407
Lifting capacity: max. 60 kg
Weight: 8 kg [18 lb]
1
2
3
