Gefen EXT-MFP - Manage EDID ► EDID Mode

page | 97
Basic Operation
Web Interface
Manage EDID ► EDID Mode
ID Name Description
1 EDID Mode Select the EDID mode from the drop-down
list for each input:
Internal - 720p 2 ch audio
Internal - 720p Multi ch
Internal - 1080p 2 ch audio
Internal - 1080p Multi ch
External - HDMI Output
External - DVI Output
Custom - User-dened
(continued on next page)
1
