Specications
Appendix
Connectors, Controls, and Indicators
Video Input • 1 x VGA 15-pin, female
• 1 x DisplayPort, 20-pin, female
• 1 x DVI-I, 29-pin, female (digital only)
• 1 x VGA HD-15, female
• 1 x Composite, RCA-type, female
Video Output • 1 x HDMI Type-A 19-pin, female
• 1 x DVI-I, 29-pin, female (digital only)
Audio Input • 2 x 3.5mm mini-stereo
• 1 x TOSLINK®, female
• 1 x S/PDIF, RCA-type, female
Audio Output • 2 x RCA-type
USB • 1 x Mini-B (factory use only)
IR Sensor • 1 x located on front panel
IR Extender • 1 x 3.5mm mini-stereo
Contact Closure • 1 x 6-pin Phoenix
IP • 1 x RJ-45
RS-232 • 1 x DB-9, female
Input Select Button • 1 x tact-type
Power / Standby Button • 1 x tact-type
Power / Standby Indicator • 1 x LED, multicolor, blue / red
Video Input Indicators • 5 x LED, green
Audio Input Indicators • 5 x LED, green
Power Connector • 1 x 3-pin Kycon KPJX-35 type, locking
(continued on next page)
