Features and Packing List
• 1 x Multi-Format Processor
• 1 x 6-pin Phoenix Plug
• 2 x L-shaped Brackets for surface mounting
• 4 x Mounting Screws for L-shaped brackets
• 2 x Mounting Screws
• 4 x Self-Adhesive Rubber Feet
• 1 x IR Remote Control
• 1 x 12V DC Power Supply
• 1 x Quick-Start Guide
Features
• Independent and congurable audio and video routing
• Supports input and output resolutions up to 1080p Full HD & 1920 x 1200 (WUXGA)
• HDCP compliant
• HDMI, DisplayPort, DVI, VGA, and Composite Video inputs
• DisplayPort input is compatible with Mac and PC computers
• TOSLINK® optical digital, S/PDIF coaxial digital, and two analog L/R audio inputs
• Each audio source can be independently assigned to any video source
• Audio sources can be temporarily switched away from their assigned video sources
• On-screen display (OSD) menu and web server interface allow easy set-up & control
• IP control via Telnet, UDP, and web server interface
• RS-232 Serial interface for use with an automation control system
• Independent IR control of up to four units in proximity, using distinct command sets
• Password-protected user and administrative access
• Advanced EDID Management for rapid integration of sources and dispays
• Assignable input naming
• System Conguration Upload/Download function
• Plug-and-Play installation with little to no set-up
• Locking power supply connector
• Rack-mountable using EXT-RACK-1U-GRY (available separately)
• Surface-mountable using the included L-brackets
Packing List
The Mulit-Format Processor ships with the items listed below. If any of these items are not
present in the box when you rst open it, immediately contact your dealer or Gefen.
