IP Conguration
Advanced Operation
The Multi-Format Processor supports IP-based control using Telnet, UDP, or the built-in
Web-based GUI. To set up IP control, the network settings may need to be congured.
The default network settings for the Multi-Format Processor are as follows:
Description IP Address / Port Description IP Address / Port
IP Address
192.168.1.72
Telnet Port
23
Subnet
255.255.255.0
Local UDP Port
50007
Gateway
192.168.1.254
Remote UDP IP
192.168.1.129
HTTP Port
80
Remote UDP Port
50008
All IP settings can be easily changed using the Gefen Syner-G Software Suite or the
Syner-G Discovery Tool App for iOS and Android. See Syner-G Discovery Tool (page
77) for more information.
Alternatively, the conguration settings can be assigned using RS-232 commands,
using the process below.
1. Launch a terminal emulation program (e.g. HyperTerminal) and use the RS-232
settings listed on the previous page.
2. Set the IP address using the #set_ipadd command.
3. Set the subnet mask using the #set_netmask command.
4. Set the gateway (router) IP address using the #set_gateway command.
5. Set the Telnet listening port using the #set_telnet_port command.
6. Set the HTTP listening port using the #set_http_port command.
7. Set the UDP remote IP address for the using the #set_udp_remote_ip command.
8. Set the UDP listening port using the #set_udp_port command.
9. Set the UDP remote port using the #set_udp_remote_port command.
10. Reboot the processor to apply all changes, then type the IP address that was
specied in step 3, in a Web browser to access the Web GUI. Use the same IP
address to Telnet to the Multi-Format Processor.
Information
Depending upon the network, all related IP, Telnet, and UDP settings will
need to be assigned. Consult your network administrator to obtain the proper
settings.
