Introduction
Getting Started
ID Name Description
4 Lock Press this button to toggle between locking
and unlocking the buttons on the front
panel.
5 Preset Press this button to select the desired
preset. See Routing Presets (page 20)
for more information.
6 Mask Press this button to mask the desired
output. See Masking / Unmasking Outputs
(page 18) for more information.
7 Volume Adjusts the output volume on the selected
output. See Increasing / Decreasing
Volume (page 21) for more information.
8 Mute Press this button to mute all audio. See
Muting / Unmuting Audio (page 23) for
more information.
9 DIP switches Sets the IR channel of the IR remote
control. In order for the IR remote control
to communicate with the matrix, both the IR
remote control and the matrix must be set
to the same IR channel. See Setting the
IR Channel (page 7) for setting the IR
channel of the IR remote control. Use Web
GUI to set the IR channel of the matrix.
See System Settings (page 73) for more
information.
10 Battery compartment
(shown open)
Accepts two 1.5V AAA-type batteries. See
Installing the Batteries (page 6) for
more information.
