page | 9
Getting Started
Installation
Application Diagram
4K Ultra HD
Displays
HDMI
DIGITAL AUDIO (TOSLINK®)
DIGITAL AUDIO (COAX)
ANALOG AUDIO (L/R)
4x
Ultra HD 600 MHz 4x4 Matrix
w/HDR and Audio De-Embedder
RS-232
USB
OR
CAT- 5
LAN
(Web Interface,
Telnet, or UDP)
EXT-RMT-EXTIRN
IR Extender
EXT-UHD600A-44
IR IN
4K Ultra HD
Sources
4x
Power Source for
Streaming Sources
2x
Power Amplifier
4x
Automation
Controller
with IR Out
Automation
Controller
with RS-232 Interface
De-Embeddeed Audio
4x
