106 ADV100 • Functions description and parameters list
23.3.26 4082 FieldbusM->S7sys ENUM Not assigned 0 10 RW FVS
23.3.30 4092 FieldbusM->S8sys ENUM Not assigned 0 10 RW FVS
23.3.34 4102 FieldbusM->S9sys ENUM Not assigned 0 10 RW FVS
23.3.38 4112 FieldbusM->S10sys ENUM Not assigned 0 10 RW FVS
23.3.42 4122 FieldbusM->S11sys ENUM Not assigned 0 10 RW FVS
23.3.46 4132 FieldbusM->S12sys ENUM Not assigned 0 10 RW FVS
23.3.50 4142 FieldbusM->S13sys ENUM Not assigned 0 10 RW FVS
23.3.54 4152 FieldbusM->S14sys ENUM Not assigned 0 10 RW FVS
23.3.58 4162 FieldbusM->S15sys ENUM Not assigned 0 10 RW FVS
23.3.62 4172 FieldbusM->S16sys ENUM Not assigned 0 10 RW FVS
Setting of the format of the datum received on the channel. When the src parameter is programmed, the format is
automatically programmed on the relative sys. If the src parameter is reset to null, the format does not change. The
value of the format can be selected from the following list, according to the parameter selected as the source:
0 Not assigned
1 Count 16
2 Count 32
3 Fill 16
4 Fill 32
5 Mdplc 16
6 Mdplc 32
7 Eu
8 Eu oat
9 Par 16
10 Par 32
If set to 0 the channel is not assigned.
If set to 1 the datum is assigned a 16-bit count.
If set to 2 the datum is assigned a 32-bit count.
If set to 3 16 bits on the channel are reserved for the datum, not used.
If set to 4 32 bits on the channel are reserved for the datum, not used.
If set to 5 the datum is assigned a 16-bit count used by MDPLC.
If set to 6 the datum is assigned a 32-bit count used by MDPLC.
If set to 7 the datum is assigned engineering units on a 16-bit integer.
If set to 8 the datum is assigned engineering units on a 32-bit integer.
If set to 9, the datum is assigned a 16-bit integer engineering unit format not in real time (5-10ms)
If set to 10 the datum is assigned a 32-bit integer engineering unit format or oat format if the associated parameter
is a oat-type parameter not in real time (5-10ms)
Note! If the sys parameter is notassigned, none of the subsequent fieldbus channels are read, even if programmed.
Menu PAR Description UM Type FB BIT Def Min Max Acc Mod
23.3.3 4024 FieldbusM->S1mon INT32 32 0 0 0 ER FVS
23.3.7 4034 FieldbusM->S2mon INT32 32 0 0 0 ER FVS
23.3.11 4044 FieldbusM->S3mon INT32 32 0 0 0 ER FVS
23.3.15 4054 FieldbusM->S4mon INT32 32 0 0 0 ER FVS
23.3.19 4064 FieldbusM->S5mon INT32 32 0 0 0 ER FVS
23.3.23 4074 FieldbusM->S6mon INT32 32 0 0 0 ER FVS
23.3.27 4084 FieldbusM->S7mon INT32 32 0 0 0 ER FVS
