110 ADV100 • Functions description and parameters list
23.4.24 4236 FieldbusS->M6mul FLOAT 1.0 1.0 1000.0 ERW FVS
23.4.28 4246 FieldbusS->M7mul FLOAT 1.0 1.0 1000.0 ERW FVS
23.4.32 4256 FieldbusS->M8mul FLOAT 1.0 1.0 1000.0 ERW FVS
23.4.36 4266 FieldbusS->M9mul FLOAT 1.0 1.0 1000.0 ERW FVS
23.4.40 4276 FieldbusS->M10mul FLOAT 1.0 1.0 1000.0 ERW FVS
23.4.44 4286 FieldbusS->M11mul FLOAT 1.0 1.0 1000.0 ERW FVS
23.4.48 4296 FieldbusS->M12mul FLOAT 1.0 1.0 1000.0 ERW FVS
23.4.52 4306 FieldbusS->M13mul FLOAT 1.0 1.0 1000.0 ERW FVS
23.4.56 4316 FieldbusS->M14mul FLOAT 1.0 1.0 1000.0 ERW FVS
23.4.60 4326 FieldbusS->M15mul FLOAT 1.0 1.0 1000.0 ERW FVS
23.4.64 4336 FieldbusS->M16mul FLOAT 1.0 1.0 1000.0 ERW FVS
The “FieldbusS->Mxmul” parameters are multipliers that the drive applies to the datum before sending it to the
bus. It is therefore possible to increase the resolution of some values read in EU and EU_oat mode, also using
decimal digits.
N.B.: The drive does not check that the multiplied parameter expressed in bits ts in a 16-bit integer. You must make
sure that the multiplier is compatible with the maximum value of the exchanged parameter and that it does not ex-
ceed the maximum size of 32768.
Example: FieldbusS->Mxmul = 10, S->M1eldbuspar= Motorspeed, SysS->M1eldbus = Eu.
If the motor is running at 100 rpm, the PLC reads the value 100 * 10 = 1000 on the rst word that is exchanged.
23.5–COMMUNICATION/WORDCOMP
Menu PAR Description UM Type FB BIT Def Min Max Acc Mod
23.5.1 4400 Wordbit0src LINK 16 6000 0 16384 ERW FVS
23.5.2 4402 Wordbit1src LINK 16 6000 0 16384 ERW FVS
23.5.3 4404 Wordbit2src LINK 16 6000 0 16384 ERW FVS
23.5.4 4406 Wordbit3src LINK 16 6000 0 16384 ERW FVS
23.5.5 4408 Wordbit4src LINK 16 6000 0 16384 ERW FVS
23.5.6 4410 Wordbit5src LINK 16 6000 0 16384 ERW FVS
23.5.7 4412 Wordbit6src LINK 16 6000 0 16384 ERW FVS
23.5.8 4414 Wordbit7src LINK 16 6000 0 16384 ERW FVS
23.5.9 4416 Wordbit8src LINK 16 6000 0 16384 ERW FVS
23.5.10 4418 Wordbit9src LINK 16 6000 0 16384 ERW FVS
23.5.11 4420 Wordbit10src LINK 16 6000 0 16384 ERW FVS
23.5.12 4422 Wordbit11src LINK 16 6000 0 16384 ERW FVS
23.5.13 4424 Wordbit12src LINK 16 6000 0 16384 ERW FVS
23.5.14 4426 Wordbit13src LINK 16 6000 0 16384 ERW FVS
23.5.15 4428 Wordbit14src LINK 16 6000 0 16384 ERW FVS
23.5.16 4430 Wordbit15src LINK 16 6000 0 16384 ERW FVS
Selection of the origin (source) of the signal to be used for coding in Wordcomp. This function allows the user
to compose a single word composed of 16 signals, each of which can be selected from among those listed in the
“L_DIGSEL1” selection list.
The values of the sectioned sizes are converted into a single word.
