gefran SIEIDrive ADV100 User Manual

8 ADV100 • Functions description and parameters list
1–MONITOR
Menu PAR Description UM Type FB BIT Def Min Max Acc Mod
1.1 250 Outputcurrent A FLOAT 16/32 0.0 0.0 0.0 R FVS
The drive output current is displayed.
Menu PAR Description UM Type FB BIT Def Min Max Acc Mod
1.2 252 Outputvoltage V FLOAT 16/32 0.0 0.0 0.0 R FVS
The drive line voltage output is displayed.
Menu PAR Description UM Type FB BIT Def Min Max Acc Mod
1.3 254 Outputfrequency Hz FLOAT 16/32 0 0 0 R FVS
The drive output frequency is displayed.
Menu PAR Description UM Type FB BIT Def Min Max Acc Mod
1.4 628 Rampsetpoint rpm INT16 16/32 0 0 0 R FVS
The ramp reference is displayed. This is the speed value the drive must reach at the end of the ramp.
Menu PAR Description UM Type FB BIT Def Min Max Acc Mod
1.5 664 Speedsetpoint rpm INT16 16/32 0 0 0 R FVS
The speed reference is displayed. This is the value measured at the output of the speed reference circuit.
Menu PAR Description UM Type FB BIT Def Min Max Acc Mod
1.6 260 Motorspeed rpm INT16 16/32 0 0 0 R FVS
The actual output speed of the motor is displayed (in FOC = speed measured by the encoder, in SLS/VF = speed
estimated by the drive).
Menu PAR Description UM Type FB BIT Def Min Max Acc Mod
1.7 270 DClinkvoltage V FLOAT 16/32 0.0 0.0 0.0 ER FVS
The direct voltage of the intermediate circuit capacitors is displayed (DC-Bus).
Menu PAR Description UM Type FB BIT Def Min Max Acc Mod
1.8 272 Heatsinktemperature degC INT16 16 0 0 0 ER FVS
The temperature measured on the drive heatsink is displayed.
Menu PAR Description UM Type FB BIT Def Min Max Acc Mod
1.9 280 Torquecurrentref A FLOAT 16/32 0.0 0.0 0.0 ER F_S
The current reference used for torque control is displayed (in the sensorless vector and eld-oriented vector modes).
Menu PAR Description UM Type FB BIT Def Min Max Acc Mod
1.10 282 Magnetcurrentref A FLOAT 16/32 0.0 0.0 0.0 ER F_S
The magnetizing current reference is displayed (in the sensorless vector and eld-oriented vector modes).
Menu PAR Description UM Type FB BIT Def Min Max Acc Mod
1.11 284 Torquecurrent A FLOAT 16/32 0.0 0.0 0.0 ER FVS
The actual torque current value is displayed.
