ADV100 • Functions description and parameters list 7
B–Parametersandfunctionsdescription(Expertlist)
Legend
Menu PAR Description UM Type FB BIT Def Min Max Acc Mod
1-MONITOR
1.1 250 Outputcurrent A FLOAT 16/32 0.0 0.0 0.0 R FVS
1.2 252 Outputvoltage V FLOAT 16/32 0.0 0.0 0.0 R FVS
Menu PAR Description UM Type FB BIT Def Min Max Acc Mod
6.23 754 Rampfreezesrc LINK 16 3480 0 16384 ERW FVS
L_DIGSEL2 (SelectionList)[*]
22.1-FUNCTIONS/SPEEDRATIO
22.1.1 3100 Inertiacomp kgm2 FLOAT 0.0 (*) 0.0 (*) 100.0 (*) ERWS F_S
(Level1menu)
(Level2menu)
Indexing of the menu and parameter
Parameter identifier
Parameter description
UM: unit of measure
Type of parameter
BIT Boolean, from modbus seen as 16 bits
ENUM Selection list, from modbus seen as 16 bits
FLOAT Real, from modbus seen as 32 bits
FBM2SIPA 16-bit unsigned integer. Only PAR of existing
parameters accepted.
FBS2MIPA 16-bit unsigned integer. Only PAR of existing
parameters accepted.
INT16 Integer with sign 16 bits, from modbus seen as 16 bits
INT32 Integer with sign 32 bits, from modbus seen as 32 bits
ILINK Selection list, from modbus seen as 16 bits
LINK Selection list, from modbus seen as 16 bits
UINT16 Integer without sign 16 bits, from modbus seen as
16 bits
UINT32 Integer without sign 32 bits, from modbus seen as
32 bits
Format of data exchanged on Fieldbus (16BIT, 32BIT)
Default value
CALCF Value calculated as a number with
floating point
CALCI Value calculated as a whole
number
SIZE Value depending on the size of the
drive
Minimum value
Maximum value
Accessibility :
E Expert
R Read
S Size (set value depending on the size of the device)
W Write
Z parameters that can be modified ONLY with the drive disa-
bled
Available in regulation mode:
V = V/f Control
S = Vect Flux OL
F = Vect Flux CL
[*]
Selectionlists:
The “... src” format parameters are linked to a selection list.
The source of the signal that will control the parameter can be
selected from the list indicated.
The lists are indicated in paragraph C of this manual.
