gefran SIEIDrive ADV100 User Manual

142 ADV100 • Selection lists
PAR Description Menu PAR Description Menu PAR Description Menu
626 Ramp ref out mon 0.0 (*)
628 Ramp setpoint 1.4
760 Ramp out mon 0.0 (*)
664 Speed setpoint 1.5
260 Motor speed 1.6
262 Motor speed nolter 0.0 (*)
2150 Encoder 1 speed 17.11
250 Output current 1.1
252 Output voltage 1.2
254 Output frequency 1.3
280 Torque current ref 1.9
282 Magnet current ref 1.10
284 Torque current 1.11
286 Magnet current 1.12
2360 Torque lim Pos Inuse 20.6
2362 Torque lim Neg Inuse 20.7
2386 Torque ref 20.11
2388 Torque ref nolter 0.0 (*)
270 DC link voltage 1.7
2162 Encoder 1 position 17.12
2154 E1 Virtual position 27.3.2
2156 E1 Revolutions 27.3.3
852 Multi ref out mon 7.24
870 Mpot setpoint 8.1
894 Mpot output mon 8.13
920 Jog output mon 9.6
3104 Inertia comp mon 22.1.3
1600 Analog input 1X mon 14.1
1650 Analog input 2X mon 14.16
368 Drive overload accum 1.14
3212 Motor overload accum 1.13
3260 Bres overload accum 1.15
272 Heatsink temperature 1.8
1060 Sequencer status 0.0 (*)
4432 Word comp mon 23.5.17
3446 Powerloss nextratio 0.0 (*)
4372 DS402 status word 0.0 (*)
4024 Fieldbus M->S1 mon 23.3.3
4034 Fieldbus M->S2 mon 23.3.7
4044 Fieldbus M->S3 mon 23.3.11
4054 Fieldbus M->S4 mon 23.3.15
4064 Fieldbus M->S5 mon 23.3.19
4074 Fieldbus M->S6 mon 23.3.23
4084 Fieldbus M->S7 mon 23.3.27
4094 Fieldbus M->S8 mon 23.3.31
4104 Fieldbus M->S9 mon 23.3.35
4114 Fieldbus M->S10 mon 23.3.39
4124 Fieldbus M->S11 mon 23.3.43
4134 Fieldbus M->S12 mon 23.3.47
4144 Fieldbus M->S13 mon 23.3.51
4154 Fieldbus M->S14 mon 23.3.55
4164 Fieldbus M->S15 mon 23.3.59
4174 Fieldbus M->S16 mon 23.3.63
3700 Pad 1 22.7.1
3702 Pad 2 22.7.2
3704 Pad 3 22.7.3
3706 Pad 4 22.7.4
3708 Pad 5 22.7.5
3710 Pad 6 22.7.6
3712 Pad 7 22.7.7
3714 Pad 8 22.7.8
3716 Pad 9 22.7.9
3718 Pad 10 22.7.10
3720 Pad 11 22.7.11
3722 Pad 12 22.7.12
3724 Pad 13 22.7.13
3726 Pad 14 22.7.14
3728 Pad 15 22.7.15
3730 Pad 16 22.7.16
4770 First alarm 0.0 (*)
4840 Alarm lo state 0.0 (*)
4842 Alarm hi state 0.0 (*)
1200 Digital input X mon 1.19
5008 Test gen out 27.1.5
(3) the XXXX parameter changes according
to the src parameter used:
4340 DS402 cw src
(3) = 4024 Fieldbus M->S1 mon 23.3.3
L_LIM
6000 Null 0.0 (*)
2380 Dig torque ref 1 20.8
1600 Analog input 1X mon 14.1
1650 Analog input 2X mon 14.16
4024 Fieldbus M->S1 mon 23.3.3
4034 Fieldbus M->S2 mon 23.3.7
4044 Fieldbus M->S3 mon 23.3.11
4054 Fieldbus M->S4 mon 23.3.15
4064 Fieldbus M->S5 mon 23.3.19
4074 Fieldbus M->S6 mon 23.3.23
4084 Fieldbus M->S7 mon 23.3.27
4094 Fieldbus M->S8 mon 23.3.31
4104 Fieldbus M->S9 mon 23.3.35
4114 Fieldbus M->S10 mon 23.3.39
4124 Fieldbus M->S11 mon 23.3.43
4134 Fieldbus M->S12 mon 23.3.47
4144 Fieldbus M->S13 mon 23.3.51
4154 Fieldbus M->S14 mon 23.3.55
4164 Fieldbus M->S15 mon 23.3.59
4174 Fieldbus M->S16 mon 23.3.63
3700 Pad 1 22.7.1
3702 Pad 2 22.7.2
3704 Pad 3 22.7.3
3706 Pad 4 22.7.4
3708 Pad 5 22.7.5
3710 Pad 6 22.7.6
3712 Pad 7 22.7.7
3714 Pad 8 22.7.8
3716 Pad 9 22.7.9
3718 Pad 10 22.7.10
3720 Pad 11 22.7.11
3722 Pad 12 22.7.12
3724 Pad 13 22.7.13
3726 Pad 14 22.7.14
3728 Pad 15 22.7.15
3730 Pad 16 22.7.16
5008 Test gen out 27.1.5
L_MLTREF
XXXX (4)
852 Multi ref out mon 7.24
894 Mpot output mon 8.13
2150 Encoder 1 speed 17.11
1600 Analog input 1X mon 14.1
1650 Analog input 2X mon 14.16
4024 Fieldbus M->S1 mon 23.3.3
4034 Fieldbus M->S2 mon 23.3.7
4044 Fieldbus M->S3 mon 23.3.11
4054 Fieldbus M->S4 mon 23.3.15
4064 Fieldbus M->S5 mon 23.3.19
4074 Fieldbus M->S6 mon 23.3.23
4084 Fieldbus M->S7 mon 23.3.27
4094 Fieldbus M->S8 mon 23.3.31
4104 Fieldbus M->S9 mon 23.3.35
4114 Fieldbus M->S10 mon 23.3.39
4124 Fieldbus M->S11 mon 23.3.43
4134 Fieldbus M->S12 mon 23.3.47
4144 Fieldbus M->S13 mon 23.3.51
4154 Fieldbus M->S14 mon 23.3.55
4164 Fieldbus M->S15 mon 23.3.59
4174 Fieldbus M->S16 mon 23.3.63
3700 Pad 1 22.7.1
3702 Pad 2 22.7.2
3704 Pad 3 22.7.3
3706 Pad 4 22.7.4
3708 Pad 5 22.7.5
3710 Pad 6 22.7.6
3712 Pad 7 22.7.7
3714 Pad 8 22.7.8
3716 Pad 9 22.7.9
3718 Pad 10 22.7.10
3720 Pad 11 22.7.11
3722 Pad 12 22.7.12
3724 Pad 13 22.7.13
3726 Pad 14 22.7.14
3728 Pad 15 22.7.15
3730 Pad 16 22.7.16
5008 Test gen out 27.1.5
(4) the XXXX parameter changes according
to the src parameter used:
610 Ramp ref 1 src
(4) = 600 Dig ramp ref 1 5.1
612 Ramp ref 2 src
(4) = 602 Dig ramp ref 2 5.2
614 Ramp ref 3 src
(4) = 604 Dig ramp ref 3 5.3
650 Speed ref 1 src
(4) = 640 Dig speed ref 1 5.15
652 Speed ref 2 src
(4) = 642 Dig speed ref 2 5.16
832 Multi ref 0 src
(4) = 800 Multi reference 0 7.1
