140 ADV100 • Selection lists
PAR Description Menu PAR Description Menu PAR Description Menu
C–SELECTIONLISTS
L_ANOUT
6000 Null 0.0 (*)
626 Ramp ref out mon 0.0 (*)
628 Ramp setpoint 1.4
760 Ramp out mon 0.0 (*)
664 Speed setpoint 1.5
260 Motor speed 1.6
262 Motor speed nolter 0.0 (*)
2150 Encoder 1 speed 17.11
250 Output current 1.1
252 Output voltage 1.2
254 Output frequency 1.3
280 Torque current ref 1.9
282 Magnet current ref 1.10
284 Torque current 1.11
286 Magnet current 1.12
2360 Torque lim Pos Inuse 20.6
2362 Torque lim Neg Inuse 20.7
2386 Torque ref 20.11
2388 Torque ref nolter 0.0 (*)
270 DC link voltage 1.7
852 Multi ref out mon 7.24
870 Mpot setpoint 8.1
894 Mpot output mon 8.13
920 Jog output mon 9.6
3104 Inertia comp mon 22.1.3
1600 Analog input 1X mon 14.1
1650 Analog input 2X mon 14.16
368 Drive overload accum 1.14
3212 Motor overload accum 1.13
3260 Bres overload accum 1.15
2232 Spd reg P gain Inuse 18.11
2234 Spd reg I gain Inuse 18.12
3446 Powerloss nextratio 0.0 (*)
3340 Energysave out 22.10.6
4024 Fieldbus M->S1 mon 23.3.3
4034 Fieldbus M->S2 mon 23.3.7
4044 Fieldbus M->S3 mon 23.3.11
4054 Fieldbus M->S4 mon 23.3.15
4064 Fieldbus M->S5 mon 23.3.19
4074 Fieldbus M->S6 mon 23.3.23
4084 Fieldbus M->S7 mon 23.3.27
4094 Fieldbus M->S8 mon 23.3.31
4104 Fieldbus M->S9 mon 23.3.35
4114 Fieldbus M->S10 mon 23.3.39
4124 Fieldbus M->S11 mon 23.3.43
4134 Fieldbus M->S12 mon 23.3.47
4144 Fieldbus M->S13 mon 23.3.51
4154 Fieldbus M->S14 mon 23.3.55
4164 Fieldbus M->S15 mon 23.3.59
4174 Fieldbus M->S16 mon 23.3.63
3700 Pad 1 22.7.1
3702 Pad 2 22.7.2
3704 Pad 3 22.7.3
3706 Pad 4 22.7.4
3708 Pad 5 22.7.5
3710 Pad 6 22.7.6
3712 Pad 7 22.7.7
3714 Pad 8 22.7.8
3716 Pad 9 22.7.9
3718 Pad 10 22.7.10
3720 Pad 11 22.7.11
3722 Pad 12 22.7.12
3724 Pad 13 22.7.13
3726 Pad 14 22.7.14
3728 Pad 15 22.7.15
3730 Pad 16 22.7.16
5008 Test gen out 27.1.5
L_CMP
XXXX (1)
626 Ramp ref out mon 0.0 (*)
628 Ramp setpoint 1.4
760 Ramp out mon 0.0 (*)
664 Speed setpoint 1.5
260 Motor speed 1.6
262 Motor speed nolter 0.0 (*)
2150 Encoder 1 speed 17.11
250 Output current 1.1
252 Output voltage 1.2
254 Output frequency 1.3
280 Torque current ref 1.9
282 Magnet current ref 1.10
284 Torque current 1.11
286 Magnet current 1.12
2386 Torque ref 20.11
2388 Torque ref nolter 0.0 (*)
270 DC link voltage 1.7
852 Multi ref out mon 7.24
870 Mpot setpoint 8.1
894 Mpot output mon 8.13
920 Jog output mon 9.6
1600 Analog input 1X mon 14.1
1650 Analog input 2X mon 14.16
368 Drive overload accum 1.14
3212 Motor overload accum 1.13
3260 Bres overload accum 1.15
4024 Fieldbus M->S1 mon 23.3.3
4034 Fieldbus M->S2 mon 23.3.7
4044 Fieldbus M->S3 mon 23.3.11
4054 Fieldbus M->S4 mon 23.3.15
4064 Fieldbus M->S5 mon 23.3.19
4074 Fieldbus M->S6 mon 23.3.23
4084 Fieldbus M->S7 mon 23.3.27
4094 Fieldbus M->S8 mon 23.3.31
4104 Fieldbus M->S9 mon 23.3.35
4114 Fieldbus M->S10 mon 23.3.39
4124 Fieldbus M->S11 mon 23.3.43
4134 Fieldbus M->S12 mon 23.3.47
4144 Fieldbus M->S13 mon 23.3.51
4154 Fieldbus M->S14 mon 23.3.55
4164 Fieldbus M->S15 mon 23.3.59
4174 Fieldbus M->S16 mon 23.3.63
3700 Pad 1 22.7.1
3702 Pad 2 22.7.2
3704 Pad 3 22.7.3
3706 Pad 4 22.7.4
3708 Pad 5 22.7.5
3710 Pad 6 22.7.6
3712 Pad 7 22.7.7
3714 Pad 8 22.7.8
3716 Pad 9 22.7.9
3718 Pad 10 22.7.10
3720 Pad 11 22.7.11
3722 Pad 12 22.7.12
3724 Pad 13 22.7.13
3726 Pad 14 22.7.14
3728 Pad 15 22.7.15
3730 Pad 16 22.7.16
(1) the XXXX parameter changes according
to the src parameter used:
960 Set speed ref src
(1) = 968 Dig set speed ref 10.11
3660 Compare input 1 src
(1) = 3650 Dig compare input 1 0.0 (*)
3662 Compare input 2 src
(1) = 3652 Dig compare input 2 0.0 (*)
L_DIGSEL1
6000 Null 0.0
6002 One 0.0 (*)
1110 Digital input E mon 0.0 (*)
1210 Digital input 1X mon 0.0 (*)
1212 Digital input 2X mon 0.0 (*)
1214 Digital input 3X mon 0.0 (*)
1216 Digital input 4X mon 0.0 (*)
1218 Digital input 5X mon 0.0 (*)
1220 Digital input 6X mon 0.0 (*)
1222 Digital input 7X mon 0.0 (*)
1224 Digital input 8X mon 0.0 (*)
1062 Drive OK 0.0 (*)
1064 Drive ready 0.0 (*)
934 Ref is 0 0.0 (*)
936 Ref is 0 delay 0.0 (*)
944 Speed is 0 0.0 (*)
946 Speed is 0 delay 0.0 (*)
956 Speed thr 1_2 mon 0.0 (*)
966 Set speed 0.0 (*)
976 Speed thr 3 mon 0.0 (*)
986 Current thr mon 0.0 (*)
1066 Enable state mon 1.16
1068 Start state mon 1.17
1070 FastStop state mon 1.18
1024 Enable cmd mon 11.13
1026 Start cmd mon 11.14
1028 FastStop cmd mon 11.15
4708 Alm dig out mon 1 0.0 (*)
4710 Alm dig out mon 2 0.0 (*)
4712 Alm dig out mon 3 0.0 (*)
4714 Alm dig out mon 4 0.0 (*)
1630 Analog inp1X<thr 0.0 (*)
1680 Analog inp2X<thr 0.0 (*)
362 Drive overload trip 0.0 (*)
3214 Motor overload trip 0.0 (*)
3262 Bres overload trip 0.0 (*)
366 Drive overload 80% 0.0 (*)
1048 FR start mon 11.20
1050 FR reverse mon 11.21
