ADV100 • Functions description and parameters list 105
If set to0 the alarm is only generated if the drive is enabled.
If set to 1 the alarm is generated even with the drive disabled.
Menu PAR Description UM Type FB BIT Def Min Max Acc Mod
23.2.6 4014 Fieldbusstate ENUM Stop 0 7 R FVS
The logic status of the eldbus connection is displayed. The value depends on the type of bus that is used.
The following logic states are displayed if the CANopen is selected:
0 Stop
1 PreOperational
2 Operational
The following logic states are displayed if the Probus eldbus is selected:
3 Error
4 WaitPRM
5 WaitCFG
6 DataExchange
7 DPError
23.3–COMMUNICATION/FIELDBUSM2S
Menu PAR Description UM Type FB BIT Def Min Max Acc Mod
23.3.1 4020 FieldbusM->S1ipa FBM2SIPA 0 0 20000 RW FVS
23.3.5 4030 FieldbusM->S2ipa FBM2SIPA 0 0 20000 RW FVS
23.3.9 4040 FieldbusM->S3ipa FBM2SIPA 0 0 20000 RW FVS
23.3.13 4050 FieldbusM->S4ipa FBM2SIPA 0 0 20000 RW FVS
23.3.17 4060 FieldbusM->S5ipa FBM2SIPA 0 0 20000 RW FVS
23.3.21 4070 FieldbusM->S6ipa FBM2SIPA 0 0 20000 RW FVS
23.3.25 4080 FieldbusM->S7ipa FBM2SIPA 0 0 20000 RW FVS
23.3.29 4090 FieldbusM->S8ipa FBM2SIPA 0 0 20000 RW FVS
23.3.33 4100 FieldbusM->S9ipa FBM2SIPA 0 0 20000 RW FVS
23.3.37 4110 FieldbusM->S10ipa FBM2SIPA 0 0 20000 RW FVS
23.3.41 4120 FieldbusM->S11ipa FBM2SIPA 0 0 20000 RW FVS
23.3.45 4130 FieldbusM->S12ipa FBM2SIPA 0 0 20000 RW FVS
23.3.49 4140 FieldbusM->S13ipa FBM2SIPA 0 0 20000 RW FVS
23.3.53 4150 FieldbusM->S14ipa FBM2SIPA 0 0 20000 RW FVS
23.3.57 4160 FieldbusM->S15ipa FBM2SIPA 0 0 20000 RW FVS
23.3.61 4170 FieldbusM->S16ipa FBM2SIPA 0 0 20000 RW FVS
Setting of the parameter to associate with the bus channel. The default setting is 0, which means channel not active.
If the parameter to be connected is a sorg (source), the channel and parameter can also be associated by modifying
the sorg parameter in its menu.
When setting a parameter, the format is also automatically set in the sys parameter.
Menu PAR Description UM Type FB BIT Def Min Max Acc Mod
23.3.2 4022 FieldbusM->S1sys ENUM Not assigned 0 10 RW FVS
23.3.6 4032 FieldbusM->S2sys ENUM Not assigned 0 10 RW FVS
23.3.10 4042 FieldbusM->S3sys ENUM Not assigned 0 10 RW FVS
23.3.14 4052 FieldbusM->S4sys ENUM Not assigned 0 10 RW FVS
23.3.18 4062 FieldbusM->S5sys ENUM Not assigned 0 10 RW FVS
23.3.22 4072 FieldbusM->S6sys ENUM Not assigned 0 10 RW FVS
