ADV100 • Functions description and parameters list 133
PARAMETERSONSELECTIONLISTS,BUTNOTDISPLAYEDONKEYPAD
Menu PAR Description UM Type FB BIT Def Min Max Acc Mod
 262 Motorspeednofilter rpm INT16 16 0 0 0 ER
This parameter indicates the unltered motor speed.
Menu PAR Description UM Type FB BIT Def Min Max Acc Mod
 362 Driveoverloadtrip BIT 16 0 0 1 ER
This signal indicates that the drive is in the overload condition. In the default condition the alarm is not triggered as
the relative action is set to Ignore.
Menu PAR Description UM Type FB BIT Def Min Max Acc Mod
 366 Driveoverload80 BIT 16 0 0 1 ER
This signal indicates that the drive has reached 80% of the thermal image accumulator (drive overload).
Menu PAR Description UM Type FB BIT Def Min Max Acc Mod
 626 Ramprefoutmon rpm INT16 16 0 0 0 ER
This parameter displays the reference value output of the ramp remference function block.
Menu PAR Description UM Type FB BIT Def Min Max Acc Mod
 760 Rampoutmon rpm INT16 16 0 0 0 ER
This parameter displays the reference value output of the ramp function block.
Menu PAR Description UM Type FB BIT Def Min Max Acc Mod
 764 Rampaccstate BIT 16 0 0 1 ER
This signal indicates whether the acceleration ramp is active.
Menu PAR Description UM Type FB BIT Def Min Max Acc Mod
 766 SRampdecstate BIT 16 0 0 1 ER
This signal indicates whether the deceleration ramp is active.
Menu PAR Description UM Type FB BIT Def Min Max Acc Mod
 934 Refis0 BIT 16 0 0 1 ER
This signal is active when the reference is below the limit set in parameter 930Reference0threshold.
Menu PAR Description UM Type FB BIT Def Min Max Acc Mod
 936 Refis0delay BIT 16 0 0 1 ER
This parameter is active when the reference is below the threshold set in parameter 930Reference0threshold.
The signal is enabled after the delay set with parameter932Referencedelay0.
Menu PAR Description UM Type FB BIT Def Min Max Acc Mod
 944 Speedis0 BIT 16 0 0 1 ER
This parameter is active when the speed is below the threshold set in parameter 940Speed0threshold.
Menu PAR Description UM Type FB BIT Def Min Max Acc Mod
 946 Speedis0delay BIT 16 0 0 1 ER
This signal is active when the reference is below the threshold set in parameter940Speed0threshold. The signal
is activated after the delay set in parameter 942Speed0delay.
