132 ADV100 • Functions description and parameters list
Menu PAR Description UM Type FB BIT Def Min Max Acc Mod
11056 Feedbackleveltime sec FLOAT 5.00 0.10 3600 RW FVS
This parameter denes the time for recognising the PIDFBlossalarm.
The alarm is generated when the PID error exceeds the level set in parameter 11054 Feedbacklevelfor longer than
the set time.
Example: suppose parameter 11002 Setpointvalof a pump pressure controller is 10 bar, 11054 Feedback level =
20% and 11056 Feedbackleveltime = 5 seconds
If the feedback remains below the 8 bar level (10 bar – (10 bar X 20%)) for more than 5 seconds, a PIDFBloss
alarm is generated.
Menu PAR Description UM Type FB BIT Def Min Max Acc Mod
11058 Feedbacklevelact ENUM Ignora 0 5 RW FVS
This parameter denes drive activity following recognition of a PIDFBloss alarm.
0 Ignore
1 Warning
2 Disable
3 Stop
4 Faststop
5 Stop & restart
Menu PAR Description UM Type FB BIT Def Min Max Acc Mod
11060 Restarttime sec FLOAT 5.00 0.10 3600 RW FVS
This parameter denes the delay before restarting after a PIDFBloss alarm.
Automatic restart only occurs if parameter 11058 Feedbacklevelactis set to Stop&restart.
