108 ADV100 • Functions description and parameters list
23.4–COMMUNICATION/FIELDBUSS2M
Menu PAR Description UM Type FB BIT Def Min Max Acc Mod
23.4.1 4180 FieldbusS->M1ipa FBM2SIPA 0 0 20000 RW FVS
23.4.5 4190 FieldbusS->M2ipa FBM2SIPA 0 0 20000 RW FVS
23.4.9 4200 FieldbusS->M3ipa FBM2SIPA 0 0 20000 RW FVS
23.4.13 4210 FieldbusS->M4ipa FBM2SIPA 0 0 20000 RW FVS
23.4.17 4220 FieldbusS->M5ipa FBM2SIPA 0 0 20000 RW FVS
23.4.21 4230 FieldbusS->M6ipa FBM2SIPA 0 0 20000 RW FVS
23.4.25 4240 FieldbusS->M7ipa FBM2SIPA 0 0 20000 RW FVS
23.4.29 4250 FieldbusS->M8ipa FBM2SIPA 0 0 20000 RW FVS
23.4.33 4260 FieldbusS->M9ipa FBM2SIPA 0 0 20000 RW FVS
23.4.37 4270 FieldbusS->M10ipa FBM2SIPA 0 0 20000 RW FVS
23.4.41 4280 FieldbusS->M11ipa FBM2SIPA 0 0 20000 RW FVS
23.4.45 4290 FieldbusS->M12ipa FBM2SIPA 0 0 20000 RW FVS
23.4.49 4300 FieldbusS->M13ipa FBM2SIPA 0 0 20000 RW FVS
23.4.53 4310 FieldbusS->M14ipa FBM2SIPA 0 0 20000 RW FVS
23.4.57 4320 FieldbusS->M15ipa FBM2SIPA 0 0 20000 RW FVS
23.4.61 4330 FieldbusS->M16ipa FBM2SIPA 0 0 20000 RW FVS
Setting of the parameter to associate with the bus channel. The default setting is 0, which means channel not active.
When setting a parameter, the format is also automatically set in the sys parameter
Menu PAR Description UM Type FB BIT Def Min Max Acc Mod
23.4.2 4182 FieldbusS->M1sys ENUM Not assigned 0 10 RW FVS
23.4.6 4192 FieldbusS->M2sys ENUM Not assigned 0 10 RW FVS
23.4.10 4202 FieldbusS->M3sys ENUM Not assigned 0 10 RW FVS
23.4.14 4212 FieldbusS->M4sys ENUM Not assigned 0 10 RW FVS
23.4.18 4222 FieldbusS->M5sys ENUM Not assigned 0 10 RW FVS
23.4.22 4232 FieldbusS->M6sys ENUM Not assigned 0 10 RW FVS
23.4.26 4242 FieldbusS->M7sys ENUM Not assigned 0 10 RW FVS
23.4.30 4252 FieldbusS->M8sys ENUM Not assigned 0 10 RW FVS
23.4.34 4262 FieldbusS->M9sys ENUM Not assigned 0 10 RW FVS
23.4.38 4272 FieldbusS->M10sys ENUM Not assigned 0 10 RW FVS
23.4.42 4282 FieldbusS->M11sys ENUM Not assigned 0 10 RW FVS
23.4.46 4292 FieldbusS->M12sys ENUM Not assigned 0 10 RW FVS
23.4.50 4302 FieldbusS->M13sys ENUM Not assigned 0 10 RW FVS
23.4.54 4312 FieldbusS->M14sys ENUM Not assigned 0 10 RW FVS
23.4.58 4322 FieldbusS->M15sys ENUM Not assigned 0 10 RW FVS
23.4.62 4332 FieldbusS->M16sys ENUM Not assigned 0 10 RW FVS
When setting the sorg parameter the format is automatically set on the relative sys. If sorg is set to null, the data
format does not change. The value of the format can be selected from the following list, according to the parameter
selected as the source:
0 Not assigned
1 Count 16
2 Count 32
3 Fill 16
4 Fill 32
