ADV100 • Functions description and parameters list 11
2–DRIVEINFO
This menu displays the information for identifying and conguring the drive.
Menu PAR Descrizione EU Tipo FB BIT Def Min Max Acc Mod
2.1 480 Driveseries UINT16 7 0 0 R FVS
The drive series identication code is displayed.
Menu PAR Description UM Type FB BIT Def Min Max Acc Mod
2.2 482 Drivesize UINT16 0 0 0 R
The drive size identication code is displayed.
Menu PAR Description UM Type FB BIT Def Min Max Acc Mod
2.3 484 Drivefamily ENUM No Power 0 0 RS FVS
The available mains voltage is displayed (e.g. 400V). The undervoltage alarm refers to this voltage value.
The condition No power occurs when the regulation board has just left from production and has never been cong-
ured for any power. The conguration adjustment for a given power is achieved by linking it to a power board and
running a Saveparameters.
0 No Power
1 380V…480V
2 -
3 -
4 230V
Menu PAR Description UM Type FB BIT Def Min Max Acc Mod
2.4 486 Driveregion ENUM EU 0 1 R FVS
Setting of the geographical area in which the drive is to be used (Europe or USA). This setting determines the factory
voltage and power supply frequency values.
0 EU (400V / 50Hz)
1 USA (460 / 60 Hz)
Menu PAR Description UM Type FB BIT Def Min Max Acc Mod
2.5 488 Drivecontcurrent A FLOAT CALCF 0.0 0.0 RZS FVS
The current that the drive can deliver continuously according to size, supply voltage and programmed switching
frequency is displayed.
Menu PAR Description UM Type FB BIT Def Min Max Acc Mod
2.6 490 Firmwarever.rel UINT16 0 0 0 R FVS
The version number and release number of the drive rmware are displayed. On the keypad these are displayed in
the version.release format. The parameter reading from the serial communication device or eldbus returns the ver-
sion in the high byte and the release in the low byte.
Menu PAR Description UM Type FB BIT Def Min Max Acc Mod
2.7 496 Firmwaretype UINT16 0 0 0 R FVS
The type of rmware installed in the drive is displayed.
Menu PAR Description UM Type FB BIT Def Min Max Acc Mod
2.8 504 Applicationver.rel UINT16 0 0 0 ER FVS
The version and release number of the application used in the drive are displayed. On the keypad these are dis-
played in version.release format. When the parameter is read via serial line or eldbus the version is returned in the
high byte and the release in the low byte.
