12 ADV100 • Functions description and parameters list
Menu PAR Description UM Type FB BIT Def Min Max Acc Mod
2.9 506 Applicationtype UINT16 0 0 0 ER FVS
The type of application currently used by the drive is displayed.
Menu PAR Description UM Type FB BIT Def Min Max Acc Mod
2.10 510 Timedrivepoweron h.min UINT32 0 0.0 0.0 ER FVS
The total time for which the drive has been powered is displayed.
Menu PAR Description UM Type FB BIT Def Min Max Acc Mod
2.11 512 Timedriveenable h.min UINT32 0 0.0 0.0 ER FVS
The time for which the enable hardware contact on the drive has been connected is displayed.
Menu PAR Description UM Type FB BIT Def Min Max Acc Mod
2.12 514 Numberpowerup UINT16 0 0 0 ER FVS
The number of times the drive has been powered on is displayed.
Menu PAR Description UM Type FB BIT Def Min Max Acc Mod
2.13 516 Timefanon h.min UINT32 0 0 0 ER FVS
The total operating time of the drive fan is displayed.
Menu PAR Description UM Type FB BIT Def Min Max Acc Mod
2.14 520 ProductS/N UINT32 0 0 0 R FVS
The drive serial number is displayed.
Menu PAR Description UM Type FB BIT Def Min Max Acc Mod
2.15 522 RegulationS/N UINT32 0 0 0 R FVS
The drive regulation card serial number is displayed.
Menu PAR Description UM Type FB BIT Def Min Max Acc Mod
2.16 524 PowerS/N UINT32 0 0 0 R FVS
The drive power card serial number is displayed.
Menu PAR Description UM Type FB BIT Def Min Max Acc Mod
2.17 526 Powerfilever.rel UINT16 0 0 0 ER FVS
The version number and release number of the drive power card are displayed.
Menu PAR Description UM Type FB BIT Def Min Max Acc Mod
2.18 530 Slot1cardtype ENUM None 0 0 R FVS
2.19 532 Slot2cardtype ENUM None 0 0 R FVS
2.20 534 Slot3cardtype ENUM None 0 0 R FVS
The type of expansion card installed in the relative slot of the drive is displayed.
0 None
1 I/O 0
769 I/O 1
1793 I/O 2
2305 I/O 3
3329 I/O 4
4865 I/O 5
5377 I/O 6
