ADV100 • Functions description and parameters list 13
8 Enc 1
264 Enc 2
520 Enc 3
776 Enc 4
4 Can/Dnet
255 Unknown
Note! SLOT 3 indicates the presence of the CAN on the regulation card in versions ADV100-...-C
Menu PAR Description UM Type FB BIT Def Min Max Acc Mod
2.21 536 Slot1cardS/N UINT32 0 0 0 R FVS
2.22 538 Slot2cardS/N UINT32 0 0 0 R FVS
2.23 540 Slot3cardS/N UINT32 0 0 0 R FVS
The serial number of the expansion card installed in the relative slot of the drive is displayed.
Menu PAR Description UM Type FB BIT Def Min Max Acc Mod
2.24 546 Fwencsl2ver.rel UINT16 0 0 0 R FVS
The version and release number of the encoder rmware used in the drive are displayed. On the keypad these are
displayed in version.release format. When the parameter is read via serial line or eldbus the version is returned in
the high byte and the release in the low byte.
Menu PAR Description UM Type FB BIT Def Min Max Acc Mod
2.25 548 Fwencsl2type UINT16 0 0 0 R FVS
The type of rmware installed in the encoder is displayed.
