104 ADV100 • Functions description and parameters list
23.2–COMMUNICATION/FIELDBUSCONFIG
Menu PAR Description UM Type FB BIT Def Min Max Acc Mod
23.2.1 4000 Fieldbustype ENUM Off 0 5 RW FVS
Setting of the type of eldbus to be used.
0 Off
1 CanOpen
2 DeviceNet
3 Probus
10 DS402 prole
If set to 0 no eldbus is selected.
If set to 1 the CanOpen eldbus prole is selected.
If set to 2 the ProBus-DP eldbus prole is selected.
If set to 3 the DeviceNet eldbus prole is selected.
If set to 10 the DS402 eldbus is selected.
Menu PAR Description UM Type FB BIT Def Min Max Acc Mod
23.2.2 4004 Fieldbusbaudrate ENUM 500k 0 12 RW FVS
Setting of the communication network speed (Baud Rate).
0 Auto
1 125k
2 250k
3 500k
4 1M
5 9600
6 19200
7 93750
8 187.5k
9 1.5M
103M
11 6M
1212M
Menu PAR Description UM Type FB BIT Def Min Max Acc Mod
23.2.3 4006 Fieldbusaddress INT16 3 0 255 RW FVS
Setting of the node address of the drive when connected to the network.
Menu PAR Description UM Type FB BIT Def Min Max Acc Mod
23.2.4 4010 FieldbusM->Senable ENUM Enable 0 1 ERWZ FVS
Setting of eldbus data updating.
0 Disable
1 Enable
If set to 0, the possibility of sending commands and references from the drive PLC via the eldbus is disabled.
If set to 1 the possibility of sending commands and references from the drive PLC via the eldbus is enabled.
Menu PAR Description UM Type FB BIT Def Min Max Acc Mod
23.2.5 4012 Fieldbusalarmmode INT32 0 0 1 ERWZ FVS
Setting of the OptBusFault alarm generation mode.
0 Off
1 On
