D.1Speedfbklossalarmaccordingtothetypeoffeedback
Note ! For the correct interpretation of the cause of the alarm trigger, it is necessary to transform the hex code indicated in pa-
rameter 17.29 SpdFbkLosscode, PAR 2172 , in the corresponding binary and verify in the encoder table that the active
bits and related description are used.
Example with encoder Endat:
PAR 2172 = A0H (hex value)
In the table “Speed fbk loss [22] alarm with absolute encoder EnDat” A0 is not indicated in the value column.
A0 should be contemplated as a bitword with meaning A0 -> 10100000 -> bit 5 and bit 7 . The following causes simulta-
neously intervene:
- Bit 5 = 20H Cause: the SSI signal interferences cause an error in the CKS or parity.
- Bit 7 = 20H Cause: The encoder has detected an incorrect operation and communicates it to the converter through the
Error bit. Bits 16..31 present the type of incorrect encoder operation detected.
● Speedfbkloss[22]alarmwithdigitalincrementalencoder
Bit Value Name Description
0 0x01 CHA Cause:no impulses or disturbance on incremental channel A.
Solution:Check the connection of the encoder-drive channel A, check the connection of the screen, check the encoder
supply voltage, check parameter 2102 Encoder1supply, check parameter 2104 Encoderinputconfig.
1 0x02 CHB Cause:no impulses or disturbance on incremental channel B.
Solution:Check the connection of the encoder-drive channel B, check the connection of the screen, check the encoder
supply voltage, check parameter 2102 Encoder1supply, check parameter 2104 Encoderinputconfig.
2 0x04 CHZ Cause:no impulses or disturbance on incremental channel Z.
Solution:Check the connection of the encoder-drive channel Z, check the connection of the screen, check the encoder
supply voltage, check parameter 2102 Encoder1supply, check parameter 2104 Encoderinputconfig, check param-
eter 2110 Encoder1signalcheck
D.1.1ResetSpeedfbklossalarm
The reasons for activating the Speedfbkloss alarm and the information acquired by the encoder are shown in
parameter 2172 SpdFbkLosscode.
If no card has been installed the Speedfbkloss [22] alarm is generated and no cause is displayed in parameter
2172 SpdFbkLosscode. Several causes may be present at the same time.
If no card is recognised, the system runs a routine that always returns Speedfbkloss [22] active without specifying
a cause.
D.1.2Encodererroralarm
Setup is performed each time the drive is turned on, regardless of the regulation mode that has been selected. If an
error is detected during setup the Encodererror alarm is generated with the following codes:
Bit Value Name Description
8 0x100
Setup
error
Cause:An error occurred during setup. When this has been signalled the information obtained from the encoder is not
reliable.
Solution:Take the action recommended for Speedfbkloss [22] alarm according to the type of encoder.
9 0x200
Compa-
tibility
error
Cause:Firmware on option card incompatible with firmware on regulation card.
When this has been signalled the information obtained from the encoder is not reliable.
Solution:Contact Gefran in order to update the firmware on the optional card.
