gefran SIEIDrive ADV100 User Manual

134 ADV100 • Functions description and parameters list
Menu PAR Description UM Type FB BIT Def Min Max Acc Mod
 956 Speedthr1_2mon BIT 16 0 0 1 ER
To display the speed threshold status: if the motor speed is higher than the value set in parameter 950 Speed
threshold1 or lower than the value set in parameter 952Speedthreshold2 this parameter assumes the value of
0.
If the motor speed is between the value of 950 Speedthreshold1 and that of 952Speedthreshold2, this param-
eter assumes the value of 1.
Use parameter 954Speedthresholddly to set a delay time for the transition from 0 to 1 of parameter 956Speed
thr1_2mon; the transition from 1 to 0 is always immediate.
When 950 Speedthreshold1 is set to a value higher than 952Speedthreshold2, if the motor speed is between
the thresholds this parameter assumes the value of 1. If 950 Speedthreshold1 is set to a value lower than 952
Speedthreshold2, the threshold status is not signicant
Menu PAR Description UM Type FB BIT Def Min Max Acc Mod
 966 Setspeed BIT 16 0 0 1 ER
This signal is active when the error between the speed reference and actual motor speed is greater than the toler-
ance set in parameter 962Setspeederror.
Menu PAR Description UM Type FB BIT Def Min Max Acc Mod
 976 Speedthr3mon BIT 16 0 0 1 ER
The status of the block that detects exceeding of the speed 3 threshold is displayed.
0 Actual speed below threshold
1 Actual speed above threshold
Menu PAR Description UM Type FB BIT Def Min Max Acc Mod
 986 Currentthrmon BIT 16 0 0 1 ER
The status of the block that detects exceeding of the current threshold is displayed.
0 Actual output current below threshold
1 Actual output current above threshold.
Menu PAR Description UM Type FB BIT Def Min Max Acc Mod
 1030 Local/remotemon BIT 16 0 0 1 ER
This signal is active when the drive is in the Remote operating mode.
0 Local
1 Remote
Menu PAR Description UM Type FB BIT Def Min Max Acc Mod
 1060 Sequencerstatus UINT16 16 0 0 0 ER
This signal indicates the state of the “machine states” that controls drive operation.
STS_INIT 0
STS_MAGN 1
STS_STOP 2
STS_START 3
STS_FS_STOP 4
STS_FS_START 5
STS_QSTOP 6
STS_FS_MAGN 7
STS_W_QSTOP 8
STS_READY 9
STS_MAGN_START 10
STS_ALM_DISABLED 11
STS_ALM_END_ACTION 12
