ADV100 • Functions description and parameters list 135
STS_ALM_STOP 13
STS_ALM_FSTOP 14
STS_ALM_R_TO_NORMAL 15
STS_READY_START 16
STS_READY_FSTOP 17
STS_ALM_NO_RESTART 18
STS_FS_MAGN_START 19
Menu PAR Description UM Type FB BIT Def Min Max Acc Mod
1062 DriveOK BIT 16 0 0 1 ER
This signal is active when the drive is in the “OK” condition and no alarms are present.
Menu PAR Description UM Type FB BIT Def Min Max Acc Mod
1064 Driveready BIT 16 0 0 1 ER
This signal is active when the drive reference is in the “Ready” to run condition.
Menu PAR Description UM Type FB BIT Def Min Max Acc Mod
1110 DigitalinputEmon BIT 16 0 0 1 ER
1210 Digitalinput1Xmon BIT 16 0 0 1 ER
1212 Digitalinput2Xmon BIT 16 0 0 1 ER
1214 Digitalinput3Xmon BIT 16 0 0 1 ER
1216 Digitalinput4Xmon BIT 16 0 0 1 ER
1218 Digitalinput5Xmon BIT 16 0 0 1 ER
1220 Digitalinput6Xmon BIT 16 0 0 1 ER
1222 Digitalinput7Xmon BIT 16 0 0 1 ER
1224 Digitalinput8Xmon BIT 16 0 0 1 ER
These signals represent the state of the corresponding digital input on the expansion card..
Menu PAR Description UM Type FB BIT Def Min Max Acc Mod
1630 Analoginp1X BIT 16 0 0 1 ER
This signal is active when the value of the analog input is below the threshold set in parameter 1620Analoginp1Xthr.
Menu PAR Description UM Type FB BIT Def Min Max Acc Mod
1680 Analoginp2X BIT 16 0 0 1 ER
This signal is active when the value of the analog input is below the threshold set in parameter 1670Analoginp2Xthr.
Menu PAR Description UM Type FB BIT Def Min Max Acc Mod
2388 Torquerefnofilter perc FLOAT 16 0 0 0 ER
The torque control reference current without lter is displayed (in sensorless vector and eld-oriented vector mode).
Menu PAR Description UM Type FB BIT Def Min Max Acc Mod
3180 Brakecontrolmon rpm INT16 16 0 0 1 ER
This parameter displays the status of the brake command.
0 Brake closed
1 Brake open
