136 ADV100 Functions description and parameters list
Menu PAR Description UM Type FB BIT Def Min Max Acc Mod
3214 Motoroverloadtrip BIT 16 0 0 1 ER
This signal is active when the drive is in the motor overload alarm condition.
Menu PAR Description UM Type FB BIT Def Min Max Acc Mod
3262 Bresoverloadtrip BIT 16 0 0 1 ER
This signal is active when the drive is in the braking resistor overload alarm condition.
Menu PAR Description UM Type FB BIT Def Min Max Acc Mod
3342 Energysaveoutrun BIT 16BIT 0 0 1 ER
This parameter is used to read whether an increase in output voltage or reduction in output voltage is being execut-
ed. This parameter may be linked to parameter 754 Rampfreezesrcto freeze the speed ramp during changes in
output voltage.
Menu PAR Description UM Type FB BIT Def Min Max Acc Mod
3374 Vfcatchout INT32 16 0 0 0 ER
The voltage applied during capture on-the-y of the motor in Vf mode is displayed.
Menu PAR Description UM Type FB BIT Def Min Max Acc Mod
3442 Powerlossrampdown BIT 16 0 0 1 ER
This parameter indicates the status of the Powerloss function deceleration ramp
0 Powerloss function deceleration ramp not ended
1 Powerloss function deceleration ramp ended
The signal is enabled at the end of the Powerloss function deceleration ramp.
The signal is disabled at different times depending on the Powerlossmode setting.
Menu PAR Description UM Type FB BIT Def Min Max Acc Mod
3446 Powerlossnextratio INT32 32 0 0 0 ER
This parameter gives the ratio between the motor speed and the speed reference.
For machines with several drives, line synchronisation can be achieved by connecting the Powerlossmode output
of the master to the Speedratiosrc input of the slave drives. The master => slave connection can be achieved via
analog signals or eldbus.
The value 2^30 corresponds to a ratio of 1.
Menu PAR Description UM Type FB BIT Def Min Max Acc Mod
3448 Powerlossnextactive BIT 16 0 0 1 ER
This parameter indicates the status of the Powerloss function
0 Powerloss not enabled
1 Powerloss enabled
The function is enabled when there is a power failure.
The function is disabled at different times depending on the Powerlossmode setting.
Menu PAR Description UM Type FB BIT Def Min Max Acc Mod
3480 Vdcctrlrampfreeze BIT 16 0 0 1 ER
This parameter displays when the deceleration ramp block is requested during the Vdccontrolfunction.
0 VdcCtrl function not enabled
