ADV100 • Functions description and parameters list 137
1 VdcCtrl function enabled
Menu PAR Description UM Type FB BIT Def Min Max Acc Mod
 4372 DS402statusword UINT16 16 0 0 65535 ER
This parameter displays the status word according to the DS402 prole. For more information reference should be
made to the eldbus manual.
Menu PAR Description UM Type FB BIT Def Min Max Acc Mod
 4708 Almdigoutmon1 BIT 16 0 0 1 ER
This signal is activated when the alarm congured in parameter 4700alarmdigsel1 is active.
Menu PAR Description UM Type FB BIT Def Min Max Acc Mod
 4710 Almdigoutmon2 BIT 16 0 0 1 ER
This signal is activated when the alarm congured in parameter 4702alarmdigsel2 is active.
Menu PAR Description UM Type FB BIT Def Min Max Acc Mod
 4712 Almdigoutmon3 BIT 16 0 0 1 ER
This signal is activated when the alarm congured in parameter 4704alarmdigsel3is active.
Menu PAR Description UM Type FB BIT Def Min Max Acc Mod
 4714 Almdigoutmon4 BIT 16 0 0 1 ER
This signal is activated when the alarm congured in parameter 4706alarmdigsel4 is active.
Menu PAR Description UM Type FB BIT Def Min Max Acc Mod
 4770 Firstalarm UINT32 16 0 0 0 ERW
This parameter displays the rst alarm to be activated.
0 No alarm
1 Overvoltage
2 Undervoltage
3 Ground fault
4 Overcurrent
5 Desaturation
6 MultiUndervolt
7 MultiOvercurr
8 MultiDesat
9 Heatsink OT
10 HeatsinkS OTUT
11 Intakeair OT
12 Motor OT
13 Drive overload
14 Motor overload
15 Bres overload
16 Phaseloss
17 Opt Bus fault
18 Opt 1 IO fault
19 Opt 2 IO fault
20 Opt Enc fault
21 External fault
22 Speed fbk loss
23 Overspeed
24 Speed ref loss
25 Emg stop alarm
26 Power down
27 Not Used1
28 Not Used2
29 Not Used3
