138 ADV100 • Functions description and parameters list
30 Not Used4
31 Not Used5
32 Not Used6
33 Plc1 fault
34 Plc2 fault
35 Plc3 fault
36 Plc4 fault
37 Plc5 fault
38 Plc6 fault
39 Plc7 fault
40 Plc8 fault
Menu PAR Description UM Type FB BIT Def Min Max Acc Mod
4780 AlarmPLC UINT16 0 0 0 ER
This parameter displays the state of the alarms generated by the application written with the internal PLC
Bit Description
0 1 = PLC 1 fault active
1 1 = PLC 2 fault active
2 1 = PLC 3 fault active
3 1 = PLC 4 fault active
4 1 = PLC 5 fault active
5 1 = PLC 6 fault active
6 1 = PLC 7 fault active
7 1 = PLC 8 fault active
Menu PAR Description UM Type FB BIT Def Min Max Acc Mod
4840 Alarmlostate UINT32 32 0 0 0 ER
This parameter displays the state of alarms 1..32 of the drive.
Bit Description
0 1 = Overvoltage active
1 1 = Undervoltage active
2 1 = Ground fault active
3 1 = Overcurrent active
4 1 = Desaturation active
5 1 – MultiUndervolt active
6 1 = MultiOvercurr active
7 1 – MultiDesat active
8 1 = Heatsink OT active
9 1 = Heatsink lin OT active
10 1 = Air OT active
11 1 = Motor OT active
12 1 = Drive overload active
13 1 = Motor overload active
14 1 = Bres overload active
15 1 = Phase loss active
16 1 = Opt bus fault active
17 1 = Opt 1 I/O fault active
18 1 = Opt 2 I/O fault active
19 1 = Opt enc fault active
20 1 = External fault active
21 1 = Fbk loss active
22 1 = Overspeed active
23 1 = Ref loss active
24 1 = Emg stop alarm active
25 1 = Power down active
26 1 = not used
