ADV100 • Functions description and parameters list 9
Menu PAR Description UM Type FB BIT Def Min Max Acc Mod
1.12 286 Magnetcurrent A FLOAT 16/32 0.0 0.0 0.0 ER FVS
The actual magnetizing current value is displayed.
Menu PAR Description UM Type FB BIT Def Min Max Acc Mod
1.13 3212 Motoroverloadaccum perc UINT16 16/32 0 0 100 ER FVS
The motor overload level is displayed (100% = alarm threshold).
Menu PAR Description UM Type FB BIT Def Min Max Acc Mod
1.14 368 Driveoverloadaccum perc UINT16 16/32 0 0 100 ER FVS
The drive overload level is displayed. An overload of 150% of the drive rated current is allowed for 60s. The ther-
mal image I²t adjusts the drive output current thresholds. During normal operation, the instantaneous output current
value can reach 180% (for 0.5 s) of the drive rated current. When the overload level par. 368 Drive overload accum
reaches 100%, the output current threshold is reduced to 100% of the rated current, and stays at that value until the
I²t integrator cycle is complete. At this point the overload of 150% will be re-activated.
Menu PAR Description UM Type FB BIT Def Min Max Acc Mod
1.15 3260 Bresoverloadaccum perc UINT16 16/32 0 0 100 ER FVS
The braking resistor overload limit is displayed (100% = alarm threshold).
Menu PAR Description UM Type FB BIT Def Min Max Acc Mod
1.16 1066 Enablestatemon BIT 16 0 0 1 R FVS
The drive Enable command status is displayed. Voltage must be present on terminal 9. The FR Forward start com-
mand is needed to start the inverter.
0 Disableddrive disabled
1 Enableddrive enabled
Menu PAR Description UM Type FB BIT Def Min Max Acc Mod
1.17 1068 Startstatemon BIT 16 0 0 1 R FVS
The drive Start command status is displayed.
Menu PAR Description UM Type FB BIT Def Min Max Acc Mod
1.18 1070 FastStopstatemon BIT 16 0 0 1 R FVS
The drive FastStop command status is displayed.
Menu PAR Descripttion UM Type FB BIT Def Min Max Acc Mod
1.19 1100 DigitalinputXmon UINT16 16 0 0 0 R FVS
The status of the digital inputs on the drive is displayed. It can also be read via a serial line or eldbus. The data are
contained in a word, where each bit is 1 if voltage is supplied to the corresponding input terminal.
1 Input enabled.
0 Input disabled.
I.e. :
0 0 0 0 0 0 0 0 0 0 1 1
Enable
DI 1
Menu PAR Description UM Type FB BIT Def Min Max Acc Mod
1.20 1300 DigitaloutputXmon UINT16 0 0 0 R FVS
The status of the digital outputs on the drive is displayed. It can also be read via a serial line or eldbus. The data
are contained in a word, where each bit is 1 if voltage is supplied to the corresponding input terminal.
