76 ADV100 • Functions description and parameters list
Selection of the origin (source) to be used for the negative torque limit. The signals that can be associated with the
function can be selected from the “L_LIM” selection list
Menu PAR Description UM Type FB BIT Def Min Max Acc Mod
20.6 2360 TorquelimPosInuse A FLOAT 16/32 0.0 0.0 0.0 ER FVS
The positive torque limit value currently being used is displayed.
Menu PAR Description UM Type FB BIT Def Min Max Acc Mod
20.7 2362 TorquelimNegInuse A FLOAT 16/32 0.0 0.0 0.0 ER FVS
The negative torque limit value currently being used is displayed.
Menu PAR Description UM Type FB BIT Def Min Max Acc Mod
20.8 2380 Digtorqueref1 perc FLOAT 16/32 0.0 -300.0 300.0 ERW F_S
Setting of a digital torque reference. The current reference value is proportional to the active motor current and de-
termines the torque value. The sign determines the torque direction.
Menu PAR Description UM Type FB BIT Def Min Max Acc Mod
20.9 2382 Torqueref1src LINK 16/32 3104 0.0 16384 ERWZ F_S
Selection of the origin (source) of the signal to be used for the torque reference. The values that can be sociabili alla
funzione sono nella lista di selezione “L_VREF”.
Menu PAR Description UM Type FB BIT Def Min Max Acc Mod
20.10 2384 Torquereffilter ms FLOAT 1.0 0.1 10.0 ERW F_S
Setting of a lter on the torque reference.
Menu PAR Description UM Type FB BIT Def Min Max Acc Mod
20.11 2386 Torqueref perc FLOAT 16/32 0.0 0.0 0.0 ER F_S
The value of the torque reference is displayed.
Menu PAR Description UM Type FB BIT Def Min Max Acc Mod
20.12 2366 TorquecurrlimRed A FLOAT 16/32BIT CALCF 0.0 CALCF ERWS F_S
Setting of the torque current limit when the 2368TorqueclimRedsrc command is enabled. The default value and
maximum value are automatically calculated by the drive whenever any changes are made to the motor plate data
and after autotuning.
Menu PAR Description UM Type FB BIT Def Min Max Acc Mod
20.13 2368 TorqueclimRedsrc LINK 16BIT 6000 0 16384 ERW F_S
Selection of the origin (source) to be used to reduce the torque current limit. When this command is enabled the
torque limit passes to the level set in parameter 2366TorquecurrlimRed. The signals that can be associated with
the function can be selected from the“L_DIGSEL2” selection list.
