Rev. 00 02/21
OptiCenter OC09 Maintenance / Repairs
73
For variants 3 and 4, the suction must also be connected and the
ball valve must be open.
The powder circuit could contain more than 20 kg of powder.
– Be sure to estimate the powder volume in the system.
– If you suspect that there is too much powder in the system, the
process must be monitored and stopped if necessary.
15. Press Start
If necessary, the cleaning process can be interrupted at any time
by pressing the stop button.
– The powder is collected in the OptiHopper
– This step can be stopped by the operator when no more powder
is returned
16 Press
– Cleaning of the ring injector (AirMover) and the connected
powder hose with compressed air pulses starts automatically
17. The automatic process step is complete when the key looks
like this. The key can be pressed once again if necessary. This is a
sign that the next cleaning phase needs to be activated.
18. Move recovery hose to cleaning position (RP)
