Generex CS121BL - Page 116

114
128
U
3/4
Alarm: Communication Lost
1 = active; 0 = not active
1
129
U
3/4
Alarm: Awaiting Power
1 = active; 0 = not active
1
130
U
3/4
Alarm: Shutdown Pending
1 = active; 0 = not active
1
131
U
3/4
Alarm: Shutdown Imminent
1 = active; 0 = not active
1
132
U
3/4
Alarm: Test In Progress
1 = active ; 0 = not active
1
133
U
3/4
AUX Port 1
1 = active (high) ; 0 = not
active (low)
1
134
U
3/4
AUX Port 2
1 = active (high) ; 0 = not
active (low)
1
135
U
3/4
AUX Port 3
1 = active (high) ; 0 = not
active (low)
1
136
U
3/4
AUX Port 4
1 = active (high) ; 0 = not
active (low)
1
137
U
3/4
SensorManager/SMTH_COM,
Sensor 1
Analog Value
1
138
U
3/4
SensorManager/SMTH_COM,
Sensor 2
Analog Value
1
139
U
3/4
SensorManager/Sensor 3
Analog Value
1
140
U
3/4
SensorManager/Sensor 4
Analog Value
1
141
U
3/4
SensorManager/Sensor 5
Analog Value
1
142
U
3/4
SensorManager/Sensor 6
Analog Value
1
143
U
3/4
SensorManager/Sensor 7
Analog Value
1
144
U
3/4
SensorManager/Sensor 8
Analog Value
1
Section OEM
Netminder for all other types
Address
Type
Function
Name
Description
Length
100
U
3/4
INVOLT
Input Voltage (l1-n)
1
101
U
3/4
INVOLT
Input Voltage (l2-n)
1
102
U
3/4
INVOLT
Input Voltage (l1-l2)
1
103
U
3/4
OUTPUTVOLT
Output Voltage (l1-n)
1
