Generex CS121BL - Page 117

115
104
U
3/4
OUTPUTVOLT
Output Voltage (l2-n)
1
105
U
3/4
OUTPUTVOLT
Output Voltage /(l1-l2)
1
106
U
3/4
OUTPUTCURR
Output Current (l1-n)
1
107
U
3/4
OUTPUTCURR
Output Current (l2-n)
1
108
U
3/4
OUTPUTWAT
Output Watts (l1-n)
1
109
U
3/4
OUTPUTWAT
Output Watts (l2-n)
1
110
U
3/4
OUTPUTWAT
Output Watts (l1-l2)
1
111
U
3/4
OUTPUTWATTOT
Output watts (total)
1
112
U
3/4
OUTPUTVA
Output VA (l1-n)
1
113
U
3/4
OUTPUTVA
Output VA (l2-n)
1
114
U
3/4
OUTPUTVA
Output VA (l1-l2)
1
115
U
3/4
OUTPUTVATOT
Output VA (total)
1
116
U
3/4
OUTPUTLOAD
Output Load (l1-n)
1
117
U
3/4
OUTPUTLOAD
Output Load (l2-n)
1
118
U
3/4
OUTPUTFREQ
Output Frequency
1
119
U
3/4
BATTVOLT
Battery Voltage
1
120
U
3/4
PERCBATT
Percentage Battery
1
121
U
3/4
DCCHARGECURR
DC Charging Current
1
122
U
3/4
CS121UPSSTAT
CS121 UPS Status
1
123
U
3/4
Alarm: Battery Bad
1 = active; 0 = not active
1
124
U
3/4
Alarm: On Battery
1 = active; 0 = not active
1
125
U
3/4
Alarm: Battery Low
1 = active; 0 = not active
1
126
U
3/4
Alarm: Battery Depleted
1 = active; 0 = not active
1
127
U
3/4
Alarm: Overtemperature
1 = active; 0 = not active
1
128
U
3/4
Alarm: Input Bad
1 = active; 0 = not active
1
129
U
3/4
Alarm: Output Bad
1 = active; 0 = not active
1
130
U
3/4
Alarm: Output Overload
1 = active; 0 = not active
1
131
U
3/4
Alarm: On Bypass
1 = active; 0 = not active
1
132
U
3/4
Alarm: Bypass Bad
1 = active; 0 = not active
1
133
U
3/4
Alarm: Output Off As
Requested
1 = active; 0 = not active
1
134
U
3/4
Alarm: UPS Off As
Requested
1 = active; 0 = not active
1
135
U
3/4
Alarm: Charger Failed
1 = active; 0 = not active
1
