Page 98 VRC2000 Installation and Operations Manual
Technical or Setup Assistance
Telephone: 800.945.7730 (USA) or 801.975.7200 (worldwide) Worldwide Web @ http://www.gentner.com
Tolerance Limits Up to four tolerance limits for each metering channel can be programmed. Two of
these limits must always be below the nominal value set for each metering channel;
two of these values must always be above the nominal value.
Two-Way Radio ConnectionsSee Four-Wire Connections.
User Access Code The user access code allows tering and status-channel readings to be taken;
commands can be issued, and alarms can be cleared.
Voice Mode The VRC2000s voice mode can be turned ON/OFF to help speed VRC2000
programming.
VRC-Win Software This software is an intuititive point-and-click Windows® software package. See
Appendix C: Accessories (Page 100).
Wiring Interface This accessory provides an alternative to the standard DB37 connectors on the
VRC2000s back panel. See Appendix C: Accesories (Page 100).
Word List The VRC2000 incorporates a special electronic-speech package that allows the
system to talk over any telephone line. This speech package has a vocabulary of
almost 800 words. See Appendix I: Word List (Page 125).
Table 15. Command 1–8 Pinout
Pin Description
1 Command 1A
2 Command 1B
3 Command 2A
4 Command 2B
5 Command 3A
6 Command 3B
7 Command 4A
8 Command 4B
9 Command 5A
10 Command 5B
11 Command 6A
12 Command 6B
13 Command 7A
14 Command 7B
15 Command 8A
16 Command 8B
17 +5Vdc through internal 220ohm resistor
18 +5Vdc through internal 220ohm resistor
19 PTT
20–37 Ground
