VRC2000 Installation and Operations Manual Page 83
Technical or Setup Assistance
Telephone: 800.945.7730 (USA) or 801.975.7200 (worldwide) Worldwide Web @ http://www.gentner.com
The VRC2000 is a highly specialized device. Repair and maintenance should
always be done by fully qualified service technicians.
CIRCUIT NOTE:
The VRC2000 contains CMOS integrated circuits. Any internal service should
only be attempted ine a static-free environment.
General Treatment
The VRC2000 is designed to operate in conditions typical of transmitter/
remote sites. The unit should be kept clean and dry to prevent damage. When
transporting the VRC2000, Gentner Communications recommends using a
static-free case or bag.
Troubleshooting
This section provides details in locating minor problems with a VRC2000.
The following measurements can help diagnose problems. Please read the
warranty in Section Two of this manual before attempting to field service a
VRC2000.
• Power Supply
Typical Readings
J7 Pin 1 = 10Vdc Digital Regulator Input
J7 Pin 3 = 20Vdc Positive Analog Regulator Input
J7 Pin 4 = -20Vdc Negative Analog Regulator Input
U23 Pin 40 = 4.8–5.2Vdc Digital Supply
U32 Pin 1 = 11.7–12.3Vdc Positive Analog Supply
U46 Pin 4 = -11.7–-12.3Vdc Negative Analog Supply
Battery OFF position = 3.6VdcRAM, Clock Backup
Repair Procedure (If Necessary)
Power-supply problems are typically incorrectly determined to be faulty
regulators. The actual cause of most power-supply problem is a bad
integrated circuit, which causes the regulator(s) to dissipate an abnormal
amount of power, or even shut down.
The digital supply-to-circuit ground continuity is from 200–300 Ohms.
A readings lower than 200 Ohms (with the power OFF), indicates an
integrated-circuit failure.
Metering-System Failure Alarms. Metering-system failure system
alarms can be generated by dirty AC power. Verify that the AC ripple on
the analog supplies is less than 30mV if the VRC2000 reports these
alarms.
• Processor Preset
Typical Readings
U23 Pin 1 = 5Vdc
Repair Procedure (If Necessary)
Check the reset circuitry. The VRC2000 automatically holds its
processor in reset if the AC line input drops below 72Vac RMS.
Maintenance and
Service
