Page 42 VRC2000 Installation and Operations Manual
Technical or Setup Assistance
Telephone: 800.945.7730 (USA) or 801.975.7200 (worldwide) • Worldwide Web @ http://www.gentner.com
VRC2000 Setup
Continued
• ALARM FOR FIRST HIGH LIMIT OF METERING CHANNEL ONE IS ... {DISABLED} ...
[BEEP]
The VRC2000 can be programmed to declare an alarm condition when the
first high tolerance limit is met on a metering channel.
• SECOND HIGH LIMIT OF METERING CHANNEL ONE IS ... {NINE THOUSAND, NINE
HUNDRED, NINETY-NINE} ... [BEEP]
This parameter acts the same as the first high tolerance limit. This is the
highest value allowed for the metering channel.
• COMMAND CHANNEL NUMBER FOR SECOND HIGH LIMIT OF METERING CHANNEL
ONE IS ... {DISABLED} ... [BEEP]
This parameter allows the specific command channel to automatically
activate if the second high tolerance limit is passed on a metering channel.
You also select the switch to be fired for that command channel.
• ALARM FOR SECOND HIGH LIMIT OF METERING CHANNEL ONE IS ... {DISABLED}
... [BEEP]
The VRC2000 can be programmed to declare an alarm condition when the
second high tolerance limit is passed on a metering channel.
There are 16 metering channels on a VRC2000. Each can be programmed
with all the parameters outlined above. The metering channels are accessed
with the codes listed in Table 8 (below):
METERING CHANNEL NOTE:
Notice that the “6” on your DTMF pad corresponds with the letter M. This is
intended to help you remember that a code beginning with a “6” will program
metering channels.
Table 8. Metering Channel Access Codes
You Enter To Access Metering Channel
☎ “6 0 1” 1
☎ “6 0 2” 2
☎ “6 0 3” 3
☎ “6 0 4” 4
☎ “6 0 5” 5
☎ “6 0 6” 6
☎ “6 0 7” 7
☎ “6 0 8” 8
☎ “6 0 9” 9
☎ “6 1 0” 10
☎ “6 1 1” 11
☎ “6 1 2” 12
☎ “6 1 3” 13
☎ “6 1 4” 14
☎ “6 1 5” 15
☎ “6 1 6” 16
