VRC2000 Installation and Operations Manual Page 99
Technical or Setup Assistance
Telephone: 800.945.7730 (USA) or 801.975.7200 (worldwide) • Worldwide Web @ http://www.gentner.com
Table 16. Command 9–16 Pinout
Pin Description
1 Command 9A
2 Command 9B
3 Command 10A
4 Command 10B
5 Command 11A
6 Command 11B
7 Command 12A
8 Command 12B
9 Command 13A
10 Command 13B
11 Command 14A
12 Command 14B
13 Command 15A
14 Command 15B
15 Command 16A
16 Command 16B
17 +5Vdc through internal 220ohm resistor
18 +5Vdc through internal 220ohm resistor
19 PTT
20–37 Ground
Table 17. Metering Pinout
Pin Description
1 Metering 1
2 Metering 2
3 Metering 3
4 Metering 4
5 Metering 5
6 Metering 6
7 Metering 7
8 Metering 8
9 Metering 9
10 Metering 10
11 Metering 11
12 Metering 12
13 Metering 13
14 Metering 14
15 Metering 15
16 Metering 16
17–19 +5Vdc (220ohm current limited)
20–37 Ground (+/- volt reference)
