VRC2000 Installation and Operations Manual Page 31
Technical or Setup Assistance
Telephone: 800.945.7730 (USA) or 801.975.7200 (worldwide) • Worldwide Web @ http://www.gentner.com
Table 7. Status Channel Access Codes
To Access
You Enter: Status Channel:
☎ “7 0 1” 1
☎ “7 0 2” 2
☎ “7 0 3” 3
☎ “7 0 4” 4
☎ “7 0 5” 5
☎ “7 0 6” 6
☎ “7 0 7” 7
☎ “7 0 8” 8
☎ “7 0 9” 9
☎ “7 1 0” 10
☎ “7 1 1” 11
☎ “7 1 2” 12
☎ “7 1 3” 13
☎ “7 1 4” 14
☎ “7 1 5” 15
☎ “7 1 6” 16
STATUS CHANNEL NOTE:
Notice that the “7” on your DTMF pad corresponds with the letter S. This is
intended to help you remember that a code starting with a “7” will program
status channels.
To program status channels, first enter the appropriate code for the channel
you would like to program. Immediately after, the VRC2000 states its
message, the desired set-up information. All codes must be entered before
the [BEEP].
SINGLE BEEP NOTE:
The VRC2000 will emit a single [BEEP] after a set-up parameter if you do not
make a new entry. If you do make a new entry after a set-up parameter is stated
by the VRC2000, the unit will [BEEP] twice.
This process will proceed more quickly if the exact codes to be programmed
are well planned. For this purpose, this manual includes worksheets in
Appendix H: Setup Worksheets (Page 117).
Status Channel Programming Exercise
The following exercise will illustrate more fully how to program status
channels.
Enter
☎ “7 0 1”
The VRC2000 will respond:
• CHANNEL IDENTIFIER FOR STATUS CHANNEL ONE IS ... {5 MILLISECONDS SILENCE, 5
MILLISECONDS SILENCE}
