Page 100 VRC2000 Installation and Operations Manual
Technical or Setup Assistance
Telephone: 800.945.7730 (USA) or 801.975.7200 (worldwide) • Worldwide Web @ http://www.gentner.com
Table 18. Status Pinout
Pin Description
1 Status 1
2 Status 2
3 Status 3
4 Status 4
5 Status 5
6 Status 6
7 Status 7
8 Status 8
9 Status 9
10 Status 10
11 Status 11
12 Status 12
13 Status 13
14 Status 14
15 Status 15
16 Status 16
17–37 Ground (+/- volt reference)
Appendix B:
Continued
A complete line of accessories is available from Gentner Communications to
allow you to customize your VRC2000 system to most effectively and efficiently
meet your needs.
The VRC2000 is supported by a complete line of accessories and options. For
more information, contact Gentner Communcations.
Software
VRC-Win
VRC-Win is designed to work with any 386 (with a math coprocessor),
486DX or better computer system. The Windows®-compatible VRC-Win
software supplements the VRC2000 and allows all information to be entered
via computer and displayed on a monitor in the intuitive point-and-click
Windows® environment. Gentner Part Number: 910-084-100
Setup VRC2000
This easy to use, menu-driven DOS software package will run on 100
percent IBM-compatible computers. With it, you can quickly program or
reprogram your VRC2000 without using a DTMF telephone. Setup
VRC2000 also includes a terminal emulation program which you can use to
directly monitor and control the VRC2000 in conjunction with the Data
Interface accessory.
The Setup VRC2000 DOS software package is free for download from the
Gentner Web Site. Connect to http:\\www.gentner.com, click the
TECHNICAL SUPPORT button, access the SITE CONTROL page, then
select Setup VRC2000 software download. Or contact Technical Support at
one of the numbers listed at the bottom of the page and request it by part
number. Gentner Part Number: 910-084-200
Appendix C:
Accessories
