5.4.8 Test motor Y (paper movement)
KKK K
19:49
OK

PAPER MOTOR
AV: 0.0A
PK: 0.6A
CS: 0.0A
GCB MOTOR
AV: 0.0A
PK: 0.8A
CS: 0.1A
OK
Start the Y motor test
PRINT
PAUSE
Finalize the Y motor
test
STOP
Motor Y moves the paper.
The test motor Y option shows:
-The average current consumption by the paper motor and GCB motor.
-The peak current consumption by the paper motor and GCB motor.
-The average current consumption at a constant speed by the paper motor and GCB motor.
MENU

MENU
MENU
MENU
