142
GERBERplotter MP Series User Manual
English
6.2 Plotter server (Server Manager)
Server Manager is the application through which a computer manages
the tasks performed by the plotter.
By default, Server Manager manages one connection to a plotter.
From the Server Manager main window, you can perform tasks such as
stop, restart, and disconnect existing connections. You can also add a
connection for each additional plotter you want to control.
The default connection when installing Server Manager is PLOTTER-DEFAULT. This connection connects a plotter
found on the same computer and uses the communication port 9999 to communicate with User Manager.
When the Server Manager application is minimized, it appears as an icon in the taskbar. Double-click
the icon to open the main dialog box.
